K-1-47

€70.000

Area

Area

47.4
Bath

Bath

1
Bed

Bed

1
Floor

Floor

1
Send Enquiry

Product description

1. Foundations

(type of foundation to choose from)*

Installation of reinforced concrete piles, wooden grillage and sip floors



A. Installation of foundation piles:

reinforced concrete bored piles Ø 250 mm, profile pipe 100*100 mm, reinforcement 12 mm.

Installation of a grillage from lumber with a total cross-section of 146*138 mm (146*92). Installation of the first floor floor covering from SIP panels made of cement particle board measuring 2700*1200*170 mm with antiseptic-treated calibrated kiln-dried lumber (46*140 mm).

B. Installation of foundation piles:

reinforced concrete bored piles Ø 250 mm, profiled reinforced concrete strip,
reinforced concrete floor.

* Foundation of your choice (the cost of the foundation type is the same if there is no slope on the site)



2. Installation of external walls:

Installation of external walls of the first floor and frames of load-bearing partitions from SIP panels made of cement particle board measuring 2700*1200*168 mm with antiseptic-treated calibrated kiln-dried lumber (46*140 mm). Installation of load-bearing partition frames made of 38*89 mm lumber (76*89 mm).

3. Roof and roofing installation:

1st grade lumber of natural moisture, antiseptic treated (rafters 50*150 mm, lathing, transverse lathing), vapor barrier A, D, insulation 150 mm, soffits (C-8 profile), roofing – metal profile (metal tile).



Additional works



Engineering communications

  • Power supply (installation of wall outlets, laying of VVGng electrical cables, allocation of groups, installation of electrical panels, installation of RCDs, installation of circuit breakers) at the rate of 3 points per room according to the explication (two sockets + switch)
  •  Ventilation (kitchen, bathroom/bathrooms, vent pipe) natural exhaust (piping, installation of roof and roofing passage elements, installation of caps/awnings)
  •  Heating (piping with preparation for installation of end devices)
  •  Water supply and sewerage (piping with preparation for installation of end devices)

Construction work

  • Installation of dormer windows in the roof.
  • Porch structure – steps.
  • Construction of a terrace on the first/second floor.
  • Balcony arrangement.
  • Installation of a canopy over a terrace or balcony.
  • Construction of a bay window (small architectural forms).
  • Roof mounted device “chalet”.
  • Installation of a cuckoo window/balcony in the roof of the attic floor.

Outdoor work

  • Construction of a drainage system.
  • Sheathing of the basement space with CSP sheets/C8 profile.
  • Exterior finishing of the facade

Interior work

  • Soundproofing of interfloor ceilings (from 3 floors).
  • Construction of internal frame (non-load-bearing) partitions with installation of sheet materials (gypsum plasterboard, gypsum fiberboard, cement particle board) and installation of insulation.
